Gilson GX 281 Back Up Unit Wiring: 3 Of 5 - YouTube Gentex 313 Installation Inspirational | Wiring Diagram Image 18 Images about Gilson GX 281 Back up unit wiring: 3 of 5 - YouTube : Gentex 313 Vs 453 | Wiring Diagram Image, Gentex 313 Installation Inspirational | Wiring Diagram Image and also Homelink Wiring Diagram - Wiring Diagram Schema. Two GPO outputs for fuel pump activation, VVT, shift light, boost control, idle control etc.Gilson GX 281 Back up unit wiring: 3 of 5 - YouTube. This allows a 10' ignition retard whilst driving. Real time ignition retard with the ignition pot. Fuel adjustable by 10% richer and leaner over the - whole range while driving. Real time fuel adjustment using the fuel pot. Files can be uploaded and stored on your computers hard drive for future use Lambda (Closed Loop Control, wideband lambda input available on request) Engine Speed, trigger per event plus TDC.
Manifold air pressure (Built in 1,5 bar manifold pressure sensor, optional 3,0 bar map sensor available) Injector time is fully programmable using the windows based Gotech PROX Tuner software Fuel injector time mapped at 500rpm from startup to 12 000rpm on a 4 cylinder engine Able to drive 4x 2ohm injectors or 6x 16 ohm injectors (depending on the mode used) Interpolation Between load sites for smooth transition Full control over electronic injectors over 32 load sites and preset RPM levels
Phased firing of injectors in modes with TDC connected. Ignition is fully programmable using serial link to Pc or laptop Soft touch RPM limiter is provided to prevent dangerously high RPM to be exceeded Ignition control input provided by engine speed and manifold pressure (TPS also available) Interpolation Between load sites for smooth timing transition Full Control over ignition timing at preset RPM intervals and 32 load sites
